SYNCHRONOUS MOTOR/GENERATOR TRAINING SYSTEM
Features
Specification:
Experiment:
• Measuring of Structures and twisted wire resistances of
Synchronizer.
• Starting Methods of Synchronous Motor.
• Testing of Phase & Load of Synchronous Motor.
• No-load and Short Testing of Synchronous Generator.
• Load Testing of Synchronous Generator.
Control Board:
Power: 3ΦAC, 220V/380V-415V, 50/60Hz,
DC Voltage Meter: 2 EA
DC Ampere Meter: 2 EA
AC Voltage Meter: 1 EA
AC Ampere Meter: 2 EA
Frequency Meter: 1 EA
Synchronous Indicator: 1 EA
MCCB: 4 EA
3 Phase Power Toggle Switch, Exciter
Power Lamp: 1 EA
Excitation Power: 1 Set
Phase Rotation Indicator: 1 Set
Condenser Type Element: 3 EA
Digital Speed Meter: 1 EA
Electric Machine Assembly: 1 Set
Style: Steel, Portable Type
Starting Switch, Phase Test Switch
Electric Machine:
Synchronous Motor: 1 Set
1. Voltage : 3ΦAC
2. Excitation Voltage
: DC 45V
3. Number of Pole : 4 Poles
4. Continuous Rating: 1500/1800rpm
5. Output : 360Wa�(1/2HP)
6. Field : Revolving- Field Type
7. Style : Semi-enclosed Type
Synchronous Generator: 1 Set
1. Voltage : 3ΦAC
2. Excitation Voltage : DC 45V
3. Number of Pole : 4 Poles
4. Continuous Rating: 1500/1800rpm
5. Output : 360Wa�(1/2HP)
6. Field : Revolving- Field Type
7. Style : Semi-enclosed Type
▣ Load Resistor Capacity: 0 ~ 360W (Optional)
▣ Experiment Manual: 1Copy, Test Lead (Banana Plug): 1Unit, Power Cable: 1EA, Dust Cover: 1Set
(Assembled by ATCL, Bangladesh).
GENERAL DESCRIPTION:
The ATCL-SM-8 is synchronous motor Generatoris an AC motor
in which at steady state the rotation of the shaft is synchro-nized with the frequency of the supply current, the rotation period is exactly equal to an
integral number of AC cycles. Synchro-nous motors contain multiphase AC
electro-magnets on the stator of the motor that create a magnetic ÿeld which
rotates in time with the oscillations of the line current.
